BDE Pressure Washer Series
The BDE Series is a portable, electric cold water pressure washer, offering a Hotsy belt-drive, triplex pump and cleaning power of 5000 PSI.
The Hotsy Model BDE-505009B is an electric-powered cold water pressure washer designed for high-pressure industrial washing where zero gas emissions are required. Operating on 230V 3-phase electrical power (48 amps), its powerful 20 HP electric motor (1765 RPM) drives a Hotsy HX5450R triplex pump at 1650 RPM via a smooth belt drive to deliver 5.0 GPM at 5000 PSI. Mounted on a 4-wheel frame with flat-free tires, it incorporates a hot water seal kit capable of receiving incoming water up to 180°F. Features include a standard hour meter, downstream soap injection, a zinc-plated variable-pressure dual-lance wand, tri-lingual labels, and a 50-foot high-pressure hose. ETL safety certified.
Specifications
Technical data
| Pressure (psi) | 5000 |
| Flow rate (gal/min) | 5 |
| Dimensions (L x W x H) (in) | 35 x 21 x 24 |
Standard Equipment
- Hose length: 50 ft
Videos
Accessories
Detergents
Additional Models
Model
BDE-505009B
Part No.
1.107-085.0
GPM
5
PSI
5000
HP
20
Electrical
230V / 3ph
Amps
48
Model
BDE-505009C
Part No.
1.107-086.0
GPM
5
PSI
5000
HP
20
Electrical
460V / 3ph
Amps
26
